BOSCH REXROTH
R979107384
$231.57 USD
- BOSCH REXROTH
- Material:R979107384
- Model:AZPB-32-2.0RQR12KB-S0022
Quantity in stock: 0
2 cm³/rev, Clockwise rotation, Straight shaft SAE J744 13-1, 2-bolt flange SAE J744 50-2 (A-A), Thread UN-2B, SAE O-Ring
The key task of external gear pumps is to convert mechanical energy (torque and rotational speed) into hydraulic energy (flow and pressure). To avoid unnecessarily high heat losses, units with high efficiencies are sought after. These are realized by means of pressure-dependent gap sealing and high-precision manufacturing technology.
Unpacked Weight: 1.2 kg
| Slide bearings for high loads |
| Long service life |
| Port connections: flanged or threaded |
| Consistent high quality based on large-volume production |
| Drive shafts according to ISO or SAE and customer specific solutions |
| Offer Drawing | Download Offer Drawing |
| Data Sheet | Download Data Sheet |
| 3D CAD | Download 3D CAD |
| Manual | Download Manual |
| Manual | Download Manual |
| Manual | Download Manual |
| Manual | Download Manual |
| Manual | Download Manual |
| Rear cover | Standard |
| Maximum rotational speed | 5000 |
| Productgroup ID | 7,21,22,23,24,25 |
| Size (geometric displacement) | 2 |
| Sealing material | NBR, shaft seal in FKM |
| Version | Corrosion resistant, pinned |
| Special version | Deviations from catalogue standards, see drawing |
| Noise level | Standard noise level |
| External gear unit | External Gear Unit |
| Application | general |
| Drive shaft | Straight shaft SAE J744 13-1 |
| Housing material | Aluminum |
| Line connection | Thread UN-2B, SAE O-Ring |
| Series | Model B (0.84 ... 10 cm³/rev) |
| Front cover | 2-bolt flange SAE J744 50-2 (A-A) |
| Maximum intermittent pressure | 250 |
| Direction of rotation | Clockwise rotation |
| Unit version | Bearing diameter 12mm |
| External gear unit function | Pump |
| Weight | 1.2 |
| Max. flow | 10.0 |
