BOSCH REXROTH
9510490089
$930.35 USD
- BOSCH REXROTH
- Material:9510490089
- Model:AZPG-22-056RQC40MB GO2
Quantity in stock: 3
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth AZPG-22-056RQC15MB (9510490089) is a high-efficiency external gear pump designed for converting mechanical energy into hydraulic energy with minimal heat loss. This model features a clockwise rotation and a straight keyed drive shaft compliant with SAE J standards, ensuring compatibility with a wide range of equipment. The unit is equipped with an SAE J 4-B bolt flange on the front cover and an SAE split flange with UNC threads for line connections, providing secure and reliable attachment points. With its robust aluminum housing and slide bearings capable of handling high loads, the AZPG-22-056RQC15MB promises durability and a long service life. The pump's maximum rotational speed supports efficient operation, while the standard noise level ensures it doesn't contribute to a noisy work environment. Additionally, the NBR sealing material contributes to the unit's resilience against various operating conditions. The geometric displacement size of this model is specified to ensure precise fluid control, and it has been manufactured to Bosch Rexroth's consistent high-quality standards that come from large-volume production. The pump's corrosion-resistant version with pinned construction enhances its reliability in harsh environments. This external gear pump can achieve a maximum intermittent pressure and has a bearing diameter of 32 mm. Its function as a pump is complemented by its standard rear cover design. With a weight of only 5.8 kg, it remains relatively lightweight for ease of installation and maintenance. Lastly, the Bosch Rexroth AZPG-22-056RQC15MB can deliver a max flow rate that aligns with its design specifications, making it suitable for general application needs where precise hydraulic energy conversion is required.
The Bosch Rexroth AZPG-22-056RQC15MB (9510490089) is a high-efficiency external gear pump designed for converting mechanical energy into hydraulic energy with minimal heat loss. This model features a clockwise rotation and a straight keyed drive shaft compliant with SAE J standards, ensuring compatibility with a wide range of equipment. The unit is equipped with an SAE J 4-B bolt flange on the front cover and an SAE split flange with UNC threads for line connections, providing secure and reliable attachment points. With its robust aluminum housing and slide bearings capable of handling high loads, the AZPG-22-056RQC15MB promises durability and a long service life. The pump's maximum rotational speed supports efficient operation, while the standard noise level ensures it doesn't contribute to a noisy work environment. Additionally, the NBR sealing material contributes to the unit's resilience against various operating conditions. The geometric displacement size of this model is specified to ensure precise fluid control, and it has been manufactured to Bosch Rexroth's consistent high-quality standards that come from large-volume production. The pump's corrosion-resistant version with pinned construction enhances its reliability in harsh environments. This external gear pump can achieve a maximum intermittent pressure and has a bearing diameter of 32 mm. Its function as a pump is complemented by its standard rear cover design. With a weight of only 5.8 kg, it remains relatively lightweight for ease of installation and maintenance. Lastly, the Bosch Rexroth AZPG-22-056RQC15MB can deliver a max flow rate that aligns with its design specifications, making it suitable for general application needs where precise hydraulic energy conversion is required.
56 cm³/rev, Clockwise rotation, Straight keyed SAE J744 22-1 , SAE J744 101-2 (B) 2-bolt flange, SAE Split flange, UNC thread
The key task of external gear pumps is to convert mechanical energy (torque and rotational speed) into hydraulic energy (flow and pressure). To avoid unnecessarily high heat losses, units with high efficiencies are sought after. These are realized by means of pressure-dependent gap sealing and high-precision manufacturing technology.
Unpacked Weight: 10.900 kg
Long service life |
Slide bearings for high loads |
Port connections: flanged or threaded |
Consistent high quality based on large-volume production |
Drive shafts according to ISO or SAE and customer specific solutions |
Offer Drawing | Download Offer Drawing |
Data Sheet | Download Data Sheet |
3D CAD | Download 3D CAD |
Manual | Download Manual |
Manual | Download Manual |
Manual | Download Manual |
Manual | Download Manual |
Manual | Download Manual |
Rear cover | Standard |
Maximum rotational speed | 2300 |
Productgroup ID | 7,21,22,23,24,25 |
Size (geometric displacement) | 56 |
Sealing material | NBR |
Version | Corrosion resistant, pinned |
Noise level | Standard noise level |
External gear unit | External Gear Unit |
Application | general |
Drive shaft | Straight keyed SAE J744 22-1 |
Housing material | Aluminum |
Line connection | SAE Split flange, UNC thread |
Series | Model G (22.5 ... 56 cm³/rev) |
Front cover | SAE J744 101-2 (B) 2-bolt flange |
Maximum intermittent pressure | 200 |
Direction of rotation | Clockwise rotation |
Unit version | Bearing diameter 26 mm |
External gear unit function | Pump |
Weight | 10.900 |
Max. flow | 128.8 |
